Introducing The Latest in Emergency Communication

An Emergency Phone unit is typically used in a high traffic area as an additional security measure for pedestrians. By having these wall-mounted call boxes, people are constantly reassured that police assistence is just a push of a button away. They are easily visible from long distances, and unlike cell phones give the dispatch center your exact location for a faster response.

Click to Enlarge

Wall-Mounted Emergency Phone

Model Number: DC-BL4 (56 & 38)

Questions?

Call us at 915-346-4735

Request a Quote!

The wall mounted emergency phone series incorporates everything that has made our stand alone towers so successful -- powder-coated noncorroding #316 stainless steel, million candlepower blue strobe, touch carbon fiber speaker, along with an advanced unidirectional intercom system -- all assembled into a compact & sturdy wall mounted body built to survive and thrive for years. The system was designed with college campuses and corporate office sites in mind.

56” high 11” wide triangular shape

When the call button is pressed, the unit engages its primary relay, activating the emergency strobe light.

When the call button is pushed, the unit automatically dials a primary telephone number. If the number is busy or does not answer, the call box will hang up and dial up to nine 'backup' numbers. A call progress lamp is provided on the front of the unit for the benefit of the hearing impaired, and flashes to indicate a call is being placed. When the call is answered, and the unit recognizes that someone is speaking to the unit, and the lamp glows continuously.

Specifications
Options/Accessories

Emergency Call Box Design - Handsfree speaker telephone. Single button operation.
Capacity - Up to 10 numbers, each up to 16 digits in length.
Response Assurance - Unit cannot be disabled by pressing call button after Emergency Mode operation sequence is started. Only remote attendant can terminate call.
Site ID - Programmable 4 digit code.
Programming - Remote via touch - tone telephone.
Power - 100 VA 1 phase 60 hz, transformer included.
Output Ratings - Power Relays: 5 AMPS at 12 VDC or 1 AMP at 110VAC
Output Duration - Duration of call
Inputs - Push-for-help button.
Telephone Line - Standard touch-tone or ratary. Dedicated or extension line
Mounting - Surface
Construction:
- Noncorroding #316 Stainless Steel.
- Touch Carbon Fiber speaker.
- Unidirectional microphone in an acoustical chamber
- Braille ADA compliant plate.
Operating Temerature: -5 degrees F to +120 degrees F

High Visibility - Large red button and heavy duty switch
Camera - Black and White, Color or Wide Angle, Low Light
Two Button - Allows one button for emergency calls and a second button for informational calls
Available Cellular Wireless - Allows emergency call box to be placed in areas where traditional telephone lines cannot be used.
voice Location Identifier Module - Allows an audible confirmation of the units location.
Line Filter - Suppresses RFI/EMI from input power line.
Decoder - Desktop device decodes and displays site ID information.
Consolidator - Call routing and switching system. Allows multiple emergency call boxes to operate with few, or no, outside lines
Fiber Optic compatible
