Home > Parking and Traffic Gates

The Traffic Gate


Barrier gates and traffic gates are an ideal solution for controlling vehicle traffic in to and out of residential and commercial parking facilities. We offer an affordable line of commercial grade quality engineered parking barrier gates designed for long life and durability. They are ideal for controlling traffic direction as well as speed through a controlled entry or exit point. They are also usefull for preventing unwarranted traffic from entering private parking areas and other restricted parking lots. Applications include venues such as airports, parking garages, apartment complexes, industrial plants, manufacturing facilities, schools, colleges and many other facilities where access control needs monitoring.


Barrier Gate


Item Number: TG-103

Just $1650.00

or

Make Us An Offer!

This barrier gate incorporates an intelligent design with innovative technologies. It is manufactured with the most robust and accurate machinery to guarantee satisfaction in quality and durability for years. With pressurized control crushing, it is classified as one of the safest parking gates in the market.

This traffic gate is very similar to the TG-102 seen below, except it does not have the LED lighted faceplate that is included in that parking barrier gate.

  • Traffic Gate Material: Aluminum.
  • Speed: 3.5 / 5 seconds (varies along the arm).
  • Arm Length: 5.5 m (can be cut into field).
  • Degree of protection: IP54.
  • Consumption: 250 W
  • Dimensions: 344 x 290 x 1090 mm.
  • Parking Barrier Gate Color: grey/orange.
  • MCBF: 5,000,000.
  • Motor Speed: 30 RPM.
  • Pressurized Control: Included.
  • Traffic Light: Included.
  • Operating Temperature: -10 to 45 °C.
  • Enbironment: Interior / Exterior.
  • Humidity: Less than 90%.
  • Wireless Controller: Up to 80 m (optional).
  • The motor of the barrier includes a special treatment for use in low temperature conditions.
  • Wireless Remote Control Interface.
  • A single structure which provides simplicity and stability.


LED Barrier Gates


Item No: TG-102

Just $2300.00

or

Make Us An Offer!

This traffic gate has a LED lit control interface. It can be activated by a wired keypad with an RF Receiver and any other access control system. For automatic closing of the lift gate arm you can add an optional magnetic loop. The unit includes an anti-crush protection system that will raise the arm in case a vehicle is underneath the traffic gate while it is closing. Its simple structure design provides simplicity and stability, while the engine of the barrier includes a special treatment that can be used in low temperature conditions.

  • Traffic Gate Material: Aluminum.
  • Lift Arm Gate: Aluminum.
  • Speed: 3.5 / 6 seconds (varies along the arm).
  • Arm Length: 5.5 m (can be cut into field).
  • Degree of protection: IP54.
  • Consumption: 250 W
  • Dimensions: 344 x 290 x 1090 mm.
  • Unit Color: Orange / Grey.
  • MCBF: 5,000,000.
  • Motor Speed: 30 RPM.
  • Pressurized Control: Included.
  • Traffic Light: Included.
  • Operating Temperature: - 30 to 45 °C.
  • Usage: Interior / Exterior.
  • Humidity: Less than 90%.
  • Wireless Controller: Up to 80 m (optional).
  • * The Parking Barrier Gate Includes: Arm Lighted Pushbutton 5.5 m.


Traffic Arm


Item Number: TG-101

Just $2700.00

or

Make us an Offer!

This particular traffic gate provides microcomputer intelligence, multiple programming options, and on-board controls for a complete and user friendly information center providing total lane management.

  • Traffic gate body made of aluminum.
  • Arm made ​​of wood or aluminum.
  • Heavy duty motor and the torque of 1/3 HP.
  • The motor has thermal overload switch.
  • Service 10,000 daily operations.
  • Advanced Omega LCD Controller with visual display
  • Power Supply Board provides multiple input/output terminals
  • Total lane management with:
  • Two built-in vehicle detectors
  • Sensitive Reversing Logic
  • Built-in diagnostics
  • Event history report
  • Back-out timer
  • 7 day memory and data storage


Parking Gate Barrier Elite


Item Number: TG-104

Our Price: $5950.00

or

Make Us An Offer!

This top of the line parking barrier gate is ideal for controlling plant access roads, toll plazas and anywhere that requires quick operation. The lift arm gate has a quick operation from 1.5 to 4 seconds (determined by the length of the arm). Its aluminum arm provides greater strength and stiffness, and tension springs used to balance the arm and achieve a perfect balance.

Direct Control System - reliable barrier has a sinusoidal motor to operate quickly while reducing the speed when the arm the barrier is nearing the end of its travel. This helps to reduce wear and stress on mechanical components.

Universal Design - Change the system of barrier arm left to right control without using additional parts or special tools.

Minimum Maintenance - The lift gate arm is designed without pulleys or limit switches. This design requires a maintenance routine 2 or 3 times per year. Additionally, the barrier has a sensor for detecting if the arm has encountered an obstacle during its cycle of raising or lowering. If so the barrier will reverse direction immediately, return to the beginning of the cycle and try again. ambient operating temperature of -36 ° to 60 ° C.



Manual Opening Traffic Gate


Item Number: TG-105

Just $2750.00

or

Make Us An Offer

Manual opening traffic gate perfect for parking garages, private residential use, access to industrial parks, hospitals, toll booths, among others.

  • Traffic gate arm made of aluminum: 3.75 m.
  • Remote-Control: Functions to raise, lower and stop the pen (included).
  • Usage-Class: Common.
  • Lift-Time Barrier: 4 sec.
  • Obstruction Detection System: Integrated.
  • Open-Type: Manual by key operator, remote and dry contact.
  • Degree of Protection: IP54.
  • Operating Humidity: Less than 95%.
  • Operating Temperature: 0 to 55 °C (use heater at temperatures below 0 °C).
  • Height of Base: 1000 mm.
  • Base width: 300 mm.
  • Base depth: 280 mm.
  • Base Color: Yellow with Black Stripes.
  • Weight: 75 kg
  • Dimensions: 1070 x 300 x 210 mm.
  • Voltage: 110 Vac.
